I .Specification:
Probe
80 elements R60, 3.5MHz multi-frequency convex probe
Probe automatic identification
Focus
4 segments dynamic electron focusing
double encoder regulations
Frequency Conversion:
2.5MHz/3.0MHz/3.5MHz/4.0MHz /5.0MHz
Image processing
Variable aperture
dynamic apodization
Dynamic filter
Edge enhancement
Digital space-time filter
8γ corrections
16 pesudo colors
Line correlation
Frame correlation
point correlation
linear interpolation
According to the user's pattern style preference, the parameter will be set up automatically and saved ,Boot default this parameter. This default of parameter can aslo be modified in the menue.
Measurement and Note
Distance
circumference/area(method of ellipse,method of loci)
heart rate
gestational weeks(BPD,GS,CRL,FL,HC,OFD,TTD,AC)
expected date of confinement and fetus weight,etc.
full-screen character annotation,with report page
Gray scale
256 levels
Gain Control
8 segments TGC and overall gain can be adjusted respectively
Permanment storage
128 images
Cine loop:
256 frames or check one by one
Output interface:
2 SVGA video outputs and 2 PAL video outputs
Extended Function:
Optional USD function,priter fuction,.5MHz trans-vaginal probe, 7.5MHz linear probe, 7.5MHz rectal probe, mobile trolley, video printer, and ulatrasonic image workstation, etc.
II.Standard Configuration:
1. One host machine
2. One convex array probe:F=3.5MHZ
3. USB port
4.10 inch LED displayer
III.Optionals probes
IV.Package size
Gross Weight/NET WEIGHT：13/10kg
Size：480X380X410(mm)
