Microbial Detection System 256 Vials Blood Culture Analyzer

Features 1. Colorimetric detection technology means faster results. 2. Results are accurate when bottles are delayed in transit. 3. The system detects a wider range of both common and fastidious organ. 4. Efficient workflow of"Scan-Load" reduces risk of error. 5. Smart temperature...
Send Inquiry

Product Introduction Specification

General Description:

This is Automated Blood Culture System with 256 vial and is sophisticated automated microbial detection systems, which could provide optimal environments for the recovery of a wide range of microorganisms, including bacteria, fungi and mycobacteria. All this in a single innovative platform that's cost effective, compact, modular, scalable.

These System is used for clinical automated culture and detection of microorganisms in

human blood or other sterile body fluids.



YSTE-BC256 is composed of a main controller and four 64-hole units.



Features:

Safe Accurate and Fast Detection of microorganisms, blood & sterile body fluids (SBF)

Detection Principle: colorimetric

Easy handling with "Touch-Scan-Load" bottle handling steps;

Friendly GUI Operation & Quick output report in 4-24 hours

Monitor growth rates continuously or semi-continuously.

Visual Audio Alert alerts for positive bottles & Malfunction

Bar-code scanner reads bottle ID

LIS accession numbers for faster, easier bottle entry

Recovery of a wide range of organisms

Unique shatter-resistant plastic bottles maximize safety

Minimum training and maintenance



Automated Blood Culture System family include:

Product name

automated microbial detection system

Function

Detecting Body Health

Color

White

Weight

280kg

Model

YSTE-BC256

Usage

Teaching



Main-02

Hot Tags: microbial detection system 256 vials blood culture analyzer, China microbial detection system 256 vials blood culture analyzer manufacturers, suppliers, factory, V1717X Panel Detector, C arm x ray machine, Vehicle mounted x ray table, , High frequency mobile X ray machine, DR flat panel detector

Model

YSTE-BC32

YSTE-BC64

YSTE-BC128

Method

Color method

Specimen

Blood or various sterile body fluid specimens

Volume

≥32 positions

≥64 positions

≥128 positions

Temperature control system

Users can set the culture temperature flexibly

Independent culture cycle

Each culture bottle can set independently of different culture cycles flexibly

Adsorption capacity

Special resin adsorption antibiotic technology, won't affect the results of Gram staining smear

Detection

Independent detector, 24 hours continuous uninterrupted real-time detection, test every 10 minutes, the detection cycle can be set according to the user's needs.

Control system

Complete software
View complete growth curve
Support several blood culture systems work together

Culture bottles

Type I Aerobic culture bottle
Type II Anaerobic culture bottle
Type III Pediatric culture bottle
Type IV L-form Bacterial culture bottle

Automation

Fully automatic detection ,without manual correction

Alarm

Sound, light, color alarm





Barcode

Double barcode management system

Remote control

HIS, LIS is avaliable

Power supply

AC110/220V±10%, 60/50Hz

Package Size(W*D*H)

765*585*650mm

780*570*1000mm

850*850*1220

Gross Weight

43kg

61kg

158kg
